MLP
Stainless Steel-Ball lock Pins
Description
MLP
Pin: AISI303 Stainless Steel Ball and spring: AISI304
Knob: Glass fiber reinforced polyamide (PA) high-tech polymer, black, with safety buckle mounting hole, resistant to solvent, oil, grease and other chemical solvents
Cylindrical body: High tech polymer, orange, matt finish
Operating temperature: - 30 ℃ to + 80 ℃
Features and applications: it is suitable for quickly fixing or connecting processing components, especially for components that need to be disassembled and reinstalled repeatedly. 17-4PH or AISI303 stainless steel has corrosion resistance. Under special sanitary, climatic and environmental conditions, ball lock pins made of this material can be used on all machinery and equipment
Instructions for use: Press the button to release the two balls and pull out or insert the pin
Select The Proper Quick Release Ball Lock Pin
1.Select the proper pin diameterStandard inch sizes are 3/16", 1/4", 5/16", 3/8", 1/2" and 5/8”. Our standard metric sizes are 5mm, 6mm, 8mm, 10mm, 12mm and 16mm2. Select the proper clamping lengthStandard inch clamping lengths range from 1/2" up to 6" and our metric grip lengths range from 10mm up to 100mm depending on the diameter. Custom lengths are also available3. Select the proper shank material-300 Series Stainless Steel-17-4PH Stainless Steel4. Select the proper handle style
